9100 Parts List
- BARREL COMPLETE
- 001-995
- CENTER WHEEL ＆ PINION
- 012-A43
- THIRD WHEEL AND PINION
- 017-A11
- FOURTH WHEEL AND PINION
- 023-A27
- CANNON PINION WITH DRIVING WHEEL
- 028-A22
- ESCAPE WHEEL AND PINION
- 032-991
- JEWELED PALLET FORK AND STAFF
- 035-702
- BALANCE WITH HAIRSPRING REGULATED
- 039-993
- CROWN WHEEL
- 058-501
- RATCHET WHEEL
- 059-802
- CLICK
- 060-551
- WINDING PINION
- 063-351
- CLUTCH WHEEL
- 064-991
- SETTING STEM
- 065-A05
- SETTING LEVER
- 067-995
- YOKE
- 071-995
- MINUTE WHEEL AND PINION
- 072-999
- HOUR WHEEL
- 075-A63
- SETTING WHEEL
- 076-751
- SETTING LEVER SPRING
- 077-996
- DIAL WASHER(1)
- 078-400
- DIAL WASHER(2)
- 078-660
- CASING CLAMP(x2) (OPTION)
- 082-060
- INTERMEDIATE DATE CORRECTING WHEEL
- 087-A72
- RATCHET SLIDING WHEEL(2)
- 087-A74
- INTERMEDIATE DATE WHEEL(1)
- 087-A93
- INTERMEDIATE DATE WHEEL(2)
- 087-A94
- INTERMEDIATE POWER RESERVE WHEEL(1)
- 087-A95
- INTERMEDIATE POWER RESERVE WHEEL(2)
- 087-A96
- INTERMEDIATE POWER RESERVE WHEEL(3)
- 087-A97
- INTERMEDIATE POWER RESERVE WHEEL(4)
- 087-B01
- RATCHET SLIDING WHEEL(1)
- 087-B08
- INTERMEDIATE REDUCTION WHEEL AND PINION(2)
- 088-252
- INTERMEDIATE REDUCTION WHEEL AND PINION(3)
- 088-253
- INTERMEDIATE REDUCTION WHEEL AND PINION(1)
- 088-254
- CAP JEWEL MOUNTED (2)
- 094-010
- CAP JEWEL MOUNTED (1)
- 094-040
- SPIRAL SPRING WITH JEWEL (1)
- 098-090
- SPIRAL SPRING WITH JEWEL (2)
- 098-090
- 24HOUR DRIVING WHEEL
- 100-818
- MONTH DRINVING WHEEL
- 103-A12
- 24HOUR WHEEL
- 103-A13
- CALENDAR CORRECTOR FINGER
- 106-860
- DATE DIAL
- 108-K9XX
- MONTH JUMPER
- 109-874
- DATE JUMPER
- 109-875
- INTERMEDIATE REDUCTION WHEEL AND PINION(1) SPRING-CLIP
- 115-101
- DAY CORRECTOR LEVER
- 116-993
- TRAIN WHEEL GUARD(AUTOMATIC)
- 117-354
- TRAIN WHEEL GUARD(MANUAL- WINDING)
- 117-361
- OSCILLATING WEIGHT
- 119-A30
- INTERMEDIATE REDUCTION WHEEL AND PINION(4)
- 138-251
- REVERSING WHEEL
- 141-251
- POWER RESERVE WHEEL
- 189-163
- DAY WHEEL
- 200-156
- DAY JUMPER
- 209-251
- CALENDAR CORRECTOR WHEEL
- 213-616
- OPERATING LEVER
- 257-152
- MONTH CORRECTOR LEVER
- 265-202
- BREAKELEVER FOR SECOND HAND
- 269-402
- DATE DIAL GUARD
- 293-A18
- MONTH WHEEL
- 294-807
- MOVEMENT HOLDER (PLASTIC)
- 500-00245
- BARREL AND TRAIN WHEEL BRIDGE
- 701-H01
- CENTER WHEEL BRIDGE
- 702-201
- UPPER PLATE FOR CALENDER
- 703-112
- PALLET BRIDGE
- 708-091
- BALANCE BRIDGE
- 710-204
- CALENDAR PLATFORM
- 713-160
- LOWER PLATE FOR CALENDER
- 719-056
- LOWER PLATE FOR BARREL COMPLETE
- 719-058
- BARREL LOWER WHEEL
- 901-A56
- CLICK SPRING
- 903-A15
- CALENDAR CORRECTOR WHEEL SPRING
- 903-A18
- MONTH CORRECTOR SPRING
- 903-A19
- SETTING LEVER PIN
- 906-A12
- SCREW FOR CLICK
- 922-820
- SCREW FOR CLICK SPRING
- 922-820
- SCREW FOR PALLET BRIDGE(x2)
- 922-820
- SCREW FOR LOWER PLATE FOR BARREL COMPLETE (x2)
- 922-940
- SCREW FOR SETTING LEVER JUMPER (x2)
- 923-630
- SCREW FOR BALANCE BRIDGE
- 923-998
- SCREW FOR BARREL AND TRAIN WHEEL BRIDGE (x5)
- 923-998
- SCREW FOR CENTER WHEEL BRIDGE
- 923-998
- SCREW FOR LOWER PLATE FOR CALENDER (x2)
- 923-998
- SCREW FOR UPPER PLATE FOR CALENDER (x4)
- 923-998
- SCREW FOR OSCILLATING WEIGHT( x3)
- 923-999
- SCREW FOR CASING CLAMP(x2) (OPTION)
- 924-752
- SCREW FOR STUD
- 927-020
- SCREW FOR CALENDAR PLATFORM
- 929-700
- SCREW FOR DATE DIAL GUARD
- 929-700
- SCREW FOR TRAIN WHEEL GUARD(MANUAL- WINDING)( x3)
- 930-701
- SCREW FOR TRAIN WHEEL GUARD(AUTOMATIC)(x2)
- 930-701
- SCREW FOR DATE DIAL GUARD (x4)
- 930-702
- ** LONGER SETTING STEM(24.0MM) **
- 065-A25
