Cal.JS05

Cal.JS05

Small Second Chronograph

Horizontal 3 Eyes

Add favorite +8

Product Information

Icon info

Category: Small Second Chronograph
Size: 12 1/2’’’
Height: 4.30mm
Accuracy: ±20 sec per month
Battery Life: 2 years
Balance Weight: Minute 0.40 μN.m
Second 0.09 μN.m
Small 0.02 μN.m

Function

Chrono 30min/sec, 24 hour

Date
*Watch case construction for JS05, JS15 and JS25 is compatible with JP11, JP15 and JP25

High Hand

JS06

Design Sample

Minimum Case Size

Minimum Case Thickness 8.8mm

Please contact us via the form for enquiries regarding products, any customer services, and etc.

To Inquiry Form

Calendar Variation

CAL.JS05-00C

JS05-00C

Date

W.Position: 4H(SLA)
W.Shape: Square
Background: White
Letter: Black

Crown Position : 3H

CAL.JS05-00Y*

JS05-00Y

Date

W.Position: 4H(SLA)
W.Shape: Square
Background: Black
Letter: White

Crown Position : 3H

CAL.JS06-00C*

JS06-00C

Date

W.Position: 4H(SLA)
W.Shape: Square
Background: White
Letter: Black

Crown Position : 3H

CAL.JS06-00X*

JS06-00X

Date

W.Position: 6H
W.Shape: Square
Background: White
Letter: Black

Crown Position : 3H

Minimum unit order : 1000pcs per each model
Lead time(*production by order) : 2 months～

Feature

MIYOTA analog quartz movements

Introducing the world of analog quartz movement developed by MIYOTA.

MIYOTA mechanical movements

Mechanical movements that fascinate the world, developed by MIYOTA.

About MIYOTA: MIYOTA is trusted by leading brands all over the world by focusing on high quality, high precision, and customer support.

Downloads: You can dowload all the materials from here. Catalogue, spec sheet, parts list, instruction manual, and so on are available.

Contact Us: Please contact us via the form for enquiries regarding products, any customer services, and etc.

JS05 Parts List

THIRD WHEEL AND PINION: 017-149
FORTH WHEEL AND PINION: 023-A25
CANNON PINION WITH DRIVING WHEEL: 028-A19
CLUTCH WHEEL: 064-790
SETTING STEM: 065-505
SETTING LEVER: 067-173
YOKE: 071-136
MINUTE WHEEL AND PINION: 072-121
HOUR WHEEL: 075-A59
SETTING WHEEL: 076-640
SETTING LEVER SPRING: 077-136
FIFTH WHEEL AND PINION: 084-700
INTERMEDIATE DATE CORRECTING WHEEL(1): 087-184
INTERMEDIATE DATE CORRECTING WHEEL(3): 087-997
INTERMEDIATE DATE CORRECTING WHEEL(4): 087-997
INTERMEDIATE DATE CORRECTING WHEEL(2): 087-A52
INTERMEDIATE SECOND-RECORDIMG WHEEL(1): 087-A84
INTERMEDIATE SECOND-RECORDIMG WHEEL(2): 087-A85
INTERMEDIATE SECOND-RECORDIMG WHEEL(3): 087-A85
INTERMEDIATE MINUTE-RECORDIMG WHEEL(1): 087-A86
INTERMEDIATE MINUTE-RECORDIMG WHEEL(2): 087-A87
INTERMEDIATE MINUTE-RECORDIMG WHEEL(3): 087-A88
INTERMEDIATE WHEEL FOR DATE: 087-A89
INTERMEDIATE DATE CORRECTING WHEEL(5): 087-A90
INTERMEDIATE WHEEL FOR 24H: 087-A91
DATE DIAL DRIVING WHEEL: 103-A11
DATE DIAL: 108-K8XX
DATE JUMPER: 109-873
WHEEL FOR 24H: 189-161
STATOR FOR CHRONOGRAPH: 190-A03
STATOR: 190-A09
SPACER FOR SWITCH CLICK STOP SPRING(1): 212-A50
SPACER FOR SWITCH CLICK STOP SPRING(2): 212-A51
SPACER FOR INTERMEDIATE DATE CORRECTING WHEEL: 212-A52
SPACER FOR SETTING STEM: 212-A53
CALENDAR CORRECTOR WHEEL: 213-615
INSULATOR FOR BATTERY CONNECTOR SPRING: 230-220
BATTERY CONNECTOR SPRING: 231-368
COIL UNIT FOR CHRONOGRAPH: 246-A33
COIL UNIT: 246-A16
SECOND CHRONOGRAPH WHEEL: 251-321
SWITCH CLICK STOP SPRING(1): 267-204
SWITCH CLICK STOP SPRING(2): 267-204
SWITCH CLICK STOP LEVER(1): 270-153
SWITCH CLICK STOP LEVER(2): 270-153
ELECTRIC CIRCUIT UNIT: 279-J99
BATTERY: 280-340
ROTOR: 285-175
ROTOR FOR SECOND CHRONOGRAPH: 285-A21
MINUTE RECORDING WHEEL: 291-212
DATE DIAL MAINTAINING PLATE: 293-A15
TRAIN WHEEL BRIDGE: 701-H21
TRAIN WHEEL BRIDGE FOR CHRONOGRAPH: 701-H22
CALENDAR PLATFORM: 713-159
SUPPORTER FOR ELECTRIC CIRCUIT UNIT: 720-931
SCREW FOR SUPPORTOR OF ELECTRIC CIRSUIT UNIT(1)(x5): 922-149
SCREW FOR CHRONOGRAPH COIL UNIT: 922-166
SCREW FOR ELECTRIC CIRCUIT OF CHRONOGRAPH (x2): 922-166
SCREW FOR ELECTRIC CIRCUIT UNIT: 923-107
SCREW FOR TRAIN WHEEL BRIDGE: 923-112
SCREW FOR SUPPORTOR OF ELECTRIC CIRSUIT UNIT(2): 923-114
SCREW FOR DATE DIAL MAINTAINING PLATE (x3): 929-809
SCREW FOR PLATE COMPLETE(2): 934-551
** LONGER SETTING STEM(23.9mm): 065-508

JS06 Parts List

THIRD WHEEL AND PINION: 017-149
FORTH WHEEL AND PINION: 023-A13
CANNON PINION WITH DRIVING WHEEL: 028-A10
CLUTCH WHEEL: 064-790
SETTING STEM: 065-505
SETTING LEVER: 067-173
YOKE: 071-136
MINUTE WHEEL AND PINION: 072-121
HOUR WHEEL: 075-A72
SETTING WHEEL: 076-640
SETTING LEVER SPRING: 077-136
FIFTH WHEEL AND PINION: 084-700
INTERMEDIATE DATE CORRECTING WHEEL(1): 087-184
INTERMEDIATE DATE CORRECTING WHEEL(3): 087-997
INTERMEDIATE DATE CORRECTING WHEEL(4): 087-997
INTERMEDIATE DATE CORRECTING WHEEL(2): 087-A52
INTERMEDIATE SECOND-RECORDIMG WHEEL(1): 087-A84
INTERMEDIATE SECOND-RECORDIMG WHEEL(2): 087-A85
INTERMEDIATE SECOND-RECORDIMG WHEEL(3): 087-A85
INTERMEDIATE MINUTE-RECORDIMG WHEEL(1): 087-A86
INTERMEDIATE MINUTE-RECORDIMG WHEEL(2): 087-A87
INTERMEDIATE MINUTE-RECORDIMG WHEEL(3): 087-A88
INTERMEDIATE WHEEL FOR DATE: 087-A89
INTERMEDIATE DATE CORRECTING WHEEL(5): 087-A90
INTERMEDIATE WHEEL FOR 24H: 087-A91
DATE DIAL DRIVING WHEEL: 103-A11
DATE DIAL: 108-K8XX
DATE JUMPER: 109-873
WHEEL FOR 24H: 189-166
STATOR FOR CHRONOGRAPH: 190-A03
STATOR: 190-A09
SPACER FOR SWITCH CLICK STOP SPRING(1): 212-A50
SPACER FOR SWITCH CLICK STOP SPRING(2): 212-A51
SPACER FOR INTERMEDIATE DATE CORRECTING WHEEL: 212-A52
SPACER FOR SETTING STEM: 212-A53
CALENDAR CORRECTOR WHEEL: 213-615
INSULATOR FOR BATTERY CONNECTOR SPRING: 230-220
BATTERY CONNECTOR SPRING: 231-368
COIL UNIT FOR CHRONOGRAPH: 246-A05
COIL UNIT: 246-A16
SECOND CHRONOGRAPH WHEEL: 251-328
SWITCH CLICK STOP SPRING(1): 267-204
SWITCH CLICK STOP SPRING(2): 267-204
SWITCH CLICK STOP LEVER(1): 270-153
SWITCH CLICK STOP LEVER(2): 270-153
ELECTRIC CIRCUIT UNIT: 279-J99
BATTERY: 280-340
ROTOR: 285-175
ROTOR FOR SECOND CHRONOGRAPH: 285-A21
MINUTE RECORDING WHEEL: 291-218
DATE DIAL MAINTAINING PLATE: 293-A15
TRAIN WHEEL BRIDGE: 701-H21
TRAIN WHEEL BRIDGE FOR CHRONOGRAPH: 701-H22
CALENDAR PLATFORM: 713-159
SUPPORTER FOR ELECTRIC CIRCUIT UNIT: 720-975
SCREW FOR SUPPORTOR OF ELECTRIC CIRSUIT UNIT(1)(x5): 922-149
SCREW FOR CHRONOGRAPH COIL UNIT: 922-166
SCREW FOR ELECTRIC CIRCUIT OF CHRONOGRAPH (x2): 922-166
SCREW FOR ELECTRIC CIRCUIT UNIT: 923-107
SCREW FOR TRAIN WHEEL BRIDGE: 923-112
SCREW FOR SUPPORTOR OF ELECTRIC CIRSUIT UNIT(2): 923-114
SCREW FOR DATE DIAL MAINTAINING PLATE (x3): 929-809
SCREW FOR PLATE COMPLETE(2): 934-551
** LONGER SETTING STEM(23.9mm): 065-508

Icon

Long battery life

Long battery life: Battery life longer than 4 years.

Parallel push button

Parallel push button: Push buttons can be set parallel for square-shaped watch case.

Shock detection

Shock detection: The SMART IC inside the movement will detect the external impact/shock and prevent hands' jumping. It will give you more flexibility for hands selection.

Super quick date adjusting

Super quick date adjusting: The date disc flips super quickly when the crown is turned for date adjusting.

Quick reset

Quick reset: The remarkable mechanism of Heart-shaped cam allows the two counters of second/minute chronograph to reset instantly. The center chronograph second hand is IC-controlled and reset smoothly.

4 Beats hand movement

4 Beats hand movement: Center chronograph hand sweeps in 1/4 second increments.

Super runner

Super runner: Watch users can take pleasure in the unique hand movements featuring a 1/20 second counter or 1/100 second counter at ultimate spead as a feature of professional chronograph.

Alarm

Alarm: The alarm will sound when the hour hand aligns with the alarm time indicator.

Click feeling of push button

Click feeling of push button: Watch users will notice the premium value of the watches from the click of push buttons.

Moon phase display

Moon phase display: A function to display waxing and waning of the moon.
Watch users can use the moon dial indication as a guide to the age or phase of the moon.

High Hand

High Hand: The height of the hand is higher than basic caliber.

Calendar Variation

Calendar Variation: Calendar Variation is available for this movement.
